Type: Live Broadcast System

colour: black

channel: 8 channel

have tally light or not: yes it have

• • • XLR-5F

• • • Lead Time : Shipped in 7 days after payment

I. Introduction

Thank you for choosing TELIKOU intercom products. FT-800 is a 4-wire eight channel main station. FT-800 not only can be connected to camera CCU, but also can be connected to BK-104 belt pack which supports Tally function. The FT-800 is suitable for television stations, communications centers, OB trucks, live performance venues and even sports facilities.

The FT-800 utilizes a wired system for stable and reliable performance. Flexible configurations, easy operation, full-duplex communication, clear and loud communication and strong noise resistance are just a few of the advantages of the FT-800.

II. Characteristics

l Announcement output

l Controllable background input

l Automatic circuit short protection and indication.

l Feedback noise suppression

l Eight channels support Tally

Technical Specification

Audio Bandwidth: 200Hz-4000Hz ±2dB

Earphone impedance: Dynamic 50-2000ohm

Microphone impedance: Dynamic 100-600ohm

4-Wire Channel Input Audio Type: Balanced

4-Wire Channel Output Audio Type: Balanced

4-Wire Channel Input Impedance: >10Kohm

4-Wire Channel Input Level:1Vp-p

4-Wire Channel Output Level: 1Vp-p

POWER SUPPLY:

AC 90-260V, Power : >45VA;

ENVIRONMENTAL:

0° - 70°C(32°-158°F)

Relative Humidity: 0-90%

DIMENSION:

19” (W) x1.75” (H) x9.48” (D), 482mm x 44.5mm x 241mm

WEIGHT:

2.8kG

Note: Please be sure equipment is well connected to the ground for personal safety and devices protection.
